International Harvester 4386 Transmission


International Harvester 4386 tractor photo
1976 - 1981
Four-wheel Drive (4WD) tractor
Steiger built
Series map:
4386
4586
230.0hp
300.0hp
Transmission
Typegear
Gears10 forward and 2 reverse
Speeds
With 23.1-30 tires.
4386  gear speeds
