Allis Chalmers 7060 Tests
|
|
| Tractor Tests | |
| NTTL 1167: diesel Power Director 2WD | |
| NTTL 1197: diesel Power Shift 2WD |
| Nebraska Tractor Test 1167 | |||
| |||
| Nebraska Tractor Test 1167 | |
| Diesel Power Director 2WD October 30 - November 11, 1974 Link: Nebraska Tractor Test 1167 file | |
| PTO performance | |
| Power at rated engine speed | 161.51 hp 120.4 kW |
| Fuel use | 10.2 gal/hour 38.6 l/hour |
| Power at rated PTO speed | 160.44 hp 119.6 kW |
| Fuel use | 10.0 gal/hour 37.9 l/hour |
| Drawbar performance | |
| Max power | 136.12 hp 101.5 kW |
| Fuel use | 10.0 gal/hour 37.9 l/hour |
| Gear 4-Slow-Hi used for power test. | |
| Max pull | 17,370 lbs 7879 kg |
| Gear 1-Slow-Hi used for pull test. | |
| Nebraska Tractor Test 1197 | |||
| |||
| Nebraska Tractor Test 1197 | |
| Diesel Power Shift 2WD November 5 - 19, 1975 Link: Nebraska Tractor Test 1197 file | |
| PTO performance | |
| Power at rated engine speed | 161.42 hp 120.4 kW |
| Fuel use | 10.2 gal/hour 38.6 l/hour |
| Power at rated PTO speed | 161.65 hp 120.5 kW |
| Fuel use | 10.1 gal/hour 38.2 l/hour |
| Drawbar performance | |
| Max power | 141.67 hp 105.6 kW |
| Fuel use | 10.3 gal/hour 39.0 l/hour |
| Gear 1-High used for power test. | |
| Max pull | 17,851 lbs 8097 kg |
| Gear 2-Low used for pull test. | |
