John Deere 4520 Transmission


John Deere 4520 tractor photo
1969 - 1970
New Generation Series
Row-Crop tractor
Series:4520
4620
Transmissions overview
8-speed partially synchronized
8-speed full power shift
Transmission
Transmission:John Deere Syncro-Range
Type:partially synchronized
Gears:8 forward and 2 reverse
Clutch:dry disc
Oil capacity:72 qts
68.1 L
Oil type:
John Deere 303

Four shift stations with two gears each, plus reverse in the first two stations. Tractor must be stopped, and clutch used, to select one of the four shift stations. Shifting between gears in the station may be performed on the move by using the clutch.
Speeds
With 20.8-38 rear tires. Foot throttle required to reach 2500 RPM transport speeds.
4520 Syncro-Range partially synchronized speeds
Transmission
Transmission:John Deere Power Shift
Type:full power shift
Gears:8 forward and 4 reverse
Clutch:wet disc
Oil capacity:64 qts
60.6 L
Oil type:
John Deere 303

Clutchless shifting on the move between all gears. Inching pedal for precise movements.
Speeds
With 20.8-38 rear tires. Foot throttle required to reach 2500 RPM transport speeds.
4520 Power Shift full power shift speeds
