Tractors > John Deere > R

John Deere R Tests



John Deere R tractor photo
1949 - 1954
Two-Cylinder Letter Series
Standard-tread tractor
Series map:
R
43.0hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 406
R fuel use from test 406
Nebraska Tractor Test 406
Diesel 5-speed 2WD
April 19 - 28, 1949
Link: Nebraska Tractor Test 406 file
Belt power (max)48.58 hp
36.2 kW
Belt fuel use (max)2.8 gal/hour
10.6 l/hour
Drawbar performance
Max power43.15 hp
32.2 kW
Gear 3 used for power test.
Max pull6644 lbs
3013 kg
Gear 1 used for pull test.
