Craftsman 917.27347


Craftsman 917.27347 lawn tractor photo
2003
DLT 3000 Series
Lawn tractor
AYP built
Series map:
917.27347
917.27348
20.0hp
20.0hp
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.27347 Engine
20HP Kohler 671cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.27347 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6.0-6
Rear tire20x10-8
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
917.27347 references literature
2003 Riding Equipment and Attachments published by Sears
