Snapper HZ14330BVE


Snapper HZ14330BVE lawn tractor photo
1997
Yard Cruiser Series
Zero-turn mower
Production
ManufacturerSnapper
TypeZero-turn mower
Snapper HZ14330BVE Engine
14HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank2.25 gal
8.5 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringpower
Brakeswet disc
CabOpen operator station.
Photos
No photos of the Snapper HZ14330BVE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Weight502 lbs
227 kg
Front tire11x4.00-4
Rear tire18x6.50-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps9
Battery volts12
References
HZ14330BVE reference literature
Legendary Quality published in 1997, by Snapper
