Craftsman 131.9689


Craftsman 131.9689 lawn tractor photo
1975
Lawn tractor
Roper built
Production
DistributorCraftsman (a part of Sears)
ManufacturerRoper
TypeLawn tractor
Original price$389 (1975 )
Craftsman 131.9689 Engine
7HP Tecumseh 245cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 131.9689 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight279 lbs
126 kg
Front tire11x4
Rear tire15x6.0
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
131.9689 reference literature
Suburban, Farm and Ranch Catalog published in 1975, by Sears
Spring and Summer Catalog published in 1975, by Sears
