Sears 1036 536.25094


Sears 1036 536.25094 lawn tractor photo
1977 - 1978
Lawn tractor
Western Tool built
Production
DistributorSears
ManufacturerWestern Tool
TypeLawn tractor
Original price$799 (1977 )
Variants
250941977 gold paint
255211978 red/white paint
Sears 1036 Engine
10HP Briggs & Stratton 399cc 1-cyl gasoline
Fuel tank1 gal
3.8 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
Brakesdisc
CabOpen operator station.
Photos
No photos of the Sears 1036 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight405 lbs
183 kg
Front tire15x6
Rear tire18x9.5
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
1036 536.25094 reference literature
Farm and Ranch Catalog published in 1977, by Sears
