Craftsman 536.25092


Craftsman 536.25092 lawn tractor photo
1977
Lawn tractor
Western Tool built
Production
DistributorCraftsman (a part of Sears)
ManufacturerWestern Tool
TypeLawn tractor
Original price$699 (1977 )
Variants
25091recoil start
25092electric start
Craftsman 536.25092 Engine
8HP Tecumseh 305cc 1-cyl gasoline
Fuel tank1 gal
3.8 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 536.25092 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight400 lbs
181 kg
Front tire15x6
Rear tire18x9.5
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
536.25092 reference literature
Farm and Ranch Catalog published in 1977, by Sears
