Gravely 830


No photo available
1980 - 1983
Riding lawn mower
Production
ManufacturerGravely
TypeRiding lawn mower
Variants
830Eelectric-start
Gravely 830 Engine
8HP Briggs & Stratton 318cc 1-cyl gasoline
Fuel tank0.75 gal
2.8 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
Brakesdisc
CabOpen operator station.
Photos
No photos of the Gravely 830 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Wheelbase44 inches
111 cm
Weight301 to 320 pounds
Front tire4.10x3.50-4
Rear tire16x6.50-8
Full dimensions and tires ...
Gravely 830 attachments
30" mid-mount mower deck
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
830 reference literature
Operator's Manual Riding Mowers (32188) published in 1979, by Gravely
