Lawn Tractors > John Deere > Z920R

John Deere Z920R



John Deere Z920R lawn tractor photo
2013 - 2016
Z900 Series
Zero-turn mower
Series map:
Z920R
Z930R
23.5hp
25.5hp
Production
ManufacturerJohn Deere
Zero-turn mower
Built in Fuquay-Varina, North Carolina, USA
John Deere Z920R Engine
23.5HP Kawasaki 726cc 2-cyl gasoline
Fuel tank11.5 gal
43.5 L
Engine details ...
John Deere Z920R Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Power steering
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the John Deere Z920R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Weight1260 lbs
571 kg
Front tire13x6.5-6
Rear tire24x12.5-12
Full dimensions and tires ...
John Deere Z920R attachments
48" mid-mount mower deck
54" mid-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps20
Battery volts12
References
Z920R references literature
Commercial Mowers published in 2015, by John Deere
