John Deere 727


John Deere 727 lawn tractor photo
2002 - 2003
700 Series
Zero-turn mower
Series map:
717
727
737
19.0hp
23.0hp
23.0hp
Production
ManufacturerJohn Deere
Zero-turn mower
Built in Fuquay-Varina, North Carolina, USA
John Deere 727 Engine
23HP Kawasaki 675cc 2-cyl gasoline
Fuel tank7.8 gal
29.5 L
Engine details ...
Mechanical
Two-wheel drive
Power steering
Open operator station.
Photos
No photos of the John Deere 727 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase48 inches
121 cm
Weight1090 lbs
494 kg
Front tire13x5-6
Rear tire23x9.5-12
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps13
Battery CCA235
Battery volts12
References
727 references literature
7-Iron Commercial Mowing Equipment published in 2002, by John Deere
