John Deere 1600 Turbo


John Deere 1600 Turbo lawn tractor photo
2002 - 2006
Front-mount mower
1600
Series:1600 Turbo
1600 Turbo Series II
Production
ManufacturerJohn Deere
TypeFront-mount mower
FactoryFuquay-Varina, North Carolina, USA
Original price$48,699 (2003 )
John Deere 1600 Turbo Engine
64HP Yanmar 1994cc 4-cyl diesel
Fuel tank15 gal
56.8 L
Engine details ...
Mechanical
Chassis4x4 MRWD 4WD
Final drivesplanetary
Differential lockmechanical front
Steeringpower
Brakeswet disc
CabTwo-post ROPS.
Photos
No photos of the John Deere 1600 Turbo are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Dimensions & Tires
Wheelbase60 inches
152 cm
Weight3950 lbs
1791 kg
Front tire26x12-12
Rear tire20x10-8
Full dimensions and tires ...
John Deere 1600 Turbo attachments
62" front-mount mower deck
42" side-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA650
Battery volts12
References
1600 Turbo reference literature
1600 Turbo Wide-Area Mower published in 2002, by John Deere
Operator's Manual Wide Area Mower 1600 Turbo (OMTCU16064) published in 2002, by John Deere
Commercial Mowing and Portable Power Equipment published in 2003, by John Deere
Commercial Mowing and Portable Power Equipment published in 2004, by John Deere
1400 and 1500 Series II / 1600 Series Mowers 2004 published by John Deere
