Craftsman 917.25659


Craftsman 917.25659 lawn tractor photo
1996
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.25659 Engine
15.5HP Kohler 426cc 1-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.25659 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6.0-6
Rear tire20x10-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery CCA240
Battery volts12
Battery AH30
Battery GroupU1R
References
917.25659 references literature
Craftsman Lawn and Garden Tractors published in 1996, by Sears
