Craftsman 917.25546


Craftsman 917.25546 lawn tractor photo
1993
LT4000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Original price$2,099 (1993 )
Craftsman 917.25546 Engine
14HP Kohler 398cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.25546 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual idler pulley
Dimensions & Tires
Weight580 lbs
263 kg
Front tire15x6.00-6
Rear tire18x9.5-8
Full dimensions and tires ...
Craftsman 917.25546 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery volts12
