Craftsman 917.27522


Craftsman 917.27522 lawn tractor photo
2001
GT 3000 Series
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeGarden tractor
Craftsman 917.27522 Engine
25HP Kohler 724cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.27522 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Front tire16x7.5-8
Rear tire24x12-12
Full dimensions and tires ...
Craftsman 917.27522 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps15
Battery CCA280
Battery volts12
Battery AH35
Battery GroupU1R
References
917.27522 reference literature
A Complete Line of 2001 Riding Equipment and Attachments published by Sears
