Craftsman 917.27208


Craftsman 917.27208 lawn tractor photo
2001
LT 1000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Craftsman 917.27208 Engine
17HP Kohler 490cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.27208 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6-6
Rear tire20x10-8
Full dimensions and tires ...
Craftsman 917.27208 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps15
Battery CCA240
Battery volts12
Battery AH30
Battery GroupU1R
References
917.27208 reference literature
A Complete Line of 2001 Riding Equipment and Attachments published by Sears
