Craftsman 917.27183


Craftsman 917.27183 lawn tractor photo
2001
LT 1000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Craftsman 917.27183 Engine
21HP Briggs & Stratton 745cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.27183 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6-6
Rear tire20x10-8
Full dimensions and tires ...
Craftsman 917.27183 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery CCA240
Battery volts12
Battery AH30
Battery GroupU1R
References
917.27183 reference literature
A Complete Line of 2001 Riding Equipment and Attachments published by Sears
