Craftsman 917.27163


Craftsman 917.27163 lawn tractor photo
2001
LT 1000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Craftsman 917.27163 Engine
16.5HP Briggs & Stratton 499cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.27163 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Craftsman 917.27163 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery CCA190
Battery volts12
Battery AH25
Battery GroupU1R
References
917.27163 reference literature
A Complete Line of 2001 Riding Equipment and Attachments published by Sears
