Craftsman 917.25774


Craftsman 917.25774 lawn tractor photo
1994 - 1995
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeGarden tractor
Original price$3,000 (1994 )
Craftsman 917.25774 Engine
22HP Kohler 624cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
Craftsman 917.25774 attachments
50" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps15
Battery volts12
