Snapper YT16


Snapper YT16 lawn tractor photo
1989 - 1990
Lawn tractor
LT16
Series:YT12YT16
Production
ManufacturerSnapper
TypeLawn tractor
Variants
YT163333-inch deck
YT164141-inch deck
YT164848-inch deck
Snapper YT16 Engine
16HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
Brakesmechanical band
CabOpen operator station.
Power Take-off (PTO)
Front PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase48 inches
121 cm
Front tire15x6.00-6
Rear tire21x7.00-10
Full dimensions and tires ...
Snapper YT16 attachments
33" mid-mount mower deck
41" mid-mount mower deck
48" mid-mount mower deck
blade
Attachment details ...
YT16 Serial Numbers
Location:Serial number decal on the rear fender deck of the tractor, behind the seat.
Electrical
Groundnegative
Battery volts12
