Honda HT-R3009


Honda HT-R3009 lawn tractor photo
1985 - 1988
Riding lawn mower
Series:HT-R3009HT-R3811
H3011
Production
ManufacturerHonda
TypeRiding lawn mower
Honda HT-R3009 Engine
8.5HP Honda 270cc 1-cyl gasoline
Fuel tank0.5 gal
1.9 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Wheelbase43.3 inches
109 cm
Weight364 lbs
165 kg
Front tire11x4.00-5
Rear tire16x6.50-8
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
HT-R3009 reference literature
HT-R3009 published in 1986, by Honda
