Lawn Tractors > Craftsman > 917.27309

Craftsman 917.27309 - engine

Craftsman 917.27309 lawn tractor photo
Garden tractor
more Craftsman 917.27309 specifications...


Engine Detail:

 Kohler CV22S
 air-cooled vertical-shaft V-Twin
 673 cc [41.1ci ]
Bore/Stroke:3.15x2.64 inches [80 x 67 mm]
Power:22 hp [16.4 kW]
Starter volts:12
Oil capacity:2.2 qts [2.1 L]
Oil change:25 h
Sparkplug:Champion RC12YC
Sparkplug gap:0.030 inches [0.762 mm]
