Allis Chalmers HB-212
|
|
| Production | |
| Manufacturer | Allis Chalmers |
| Garden tractor | |
| Built in Lexington, South Carolina, USA | |
| Allis Chalmers HB-212 Engine | |
| 12HP Briggs & Stratton 494cc 1-cyl gasoline | |
| Fuel tank | 1.5 gal 5.7 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Allis Chalmers HB-212 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Mid PTO | live |
| Front PTO | live |
| Dimensions & Tires | |
| Wheelbase | 48 inches 121 cm |
| Weight | 745 lbs 337 kg |
 Full dimensions and tires ... | |
| Allis Chalmers HB-212 attachments | |
| 42" mid-mount mower deck | |
| 48" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Service Manual B Series Tractors (9003453) published in 1976 |
