Lawn Tractors > Gilson > 53020 H-16

Gilson 53020 H-16



Gilson 53020 H-16 lawn tractor photo
1974 - 1975
S Series
Garden tractor
Production
ManufacturerGilson
TypeGarden tractor
Variants
53020turf tires
53022ag tires
Gilson 53020 Engine
16HP Briggs & Stratton 531cc 1-cyl gasoline
Engine details ...
Gilson 53020 Transmission
hydrostatic
Transmission details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
Gilson H-16 with snowblower and soft cab.
Gilson 53020 photos...
Dimensions & Tires
Wheelbase44 inches
111 cm
Weight720 lbs
326 kg
Front tire16x6.50x8
Rear tire23x8.50-12
Full dimensions and tires ...
Gilson 53020 attachments
42" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
53020 H-16 reference literature
Heavyweight Tractors published in 1974, by Gilson
