Craftsman 131.9646


Craftsman 131.9646 lawn tractor photo
1969 - 1972
Model year
Lawn tractor
Roper built
Production
DistributorCraftsman (a part of Sears)
ManufacturerRoper
Lawn tractor
Original price was $550 in 1970
Variants
131.9641recoil start
131.9646electric start
Craftsman 131.9646 Engine
7HP Tecumseh 245cc 1-cyl gasoline
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Dimensions & Tires
Weight390 lbs
176 kg
Front tire11.00x4
Rear tire14.00x5.5
Full dimensions and tires ...
131.9646 Serial Numbers
1969131.96460 (model code)
1970131.96461 (model code)
1971131.96465 (model code)
1972131.96467 (model code)

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery volts12
References
131.9646 references literature
Craftsman Lawn Care Products published in 1969, by Sears
Spring - Summer Catalog published in 1969, by Sears
