MTD 480


MTD 480 lawn tractor photo
1970 - 1976
Lawn tractor
Production
Manufacturer:MTD
Type:Lawn tractor
Variants
480:manual start
485:electric start
MTD 480 Engine
8HP Briggs & Stratton 318cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
Transmission:1-speed CVT
Transmission details ...
Photos
No photos of the MTD 480 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Power Take-off (PTO)
Mid PTO:independent
Clutch:manual
Dimensions & Tires
Front tire:12.50x4.50-6
Rear tire:16.00x6.50-8
Full dimensions and tires ...
MTD 480 attachments
34" mid-mount mower deck
38" mid-mount mower deck
Attachment details ...
480 Serial Numbers
Location:Serial number tag on the rear fender, under the seat. Model codes shown in parentheses.
1970: (130-480)
1971: (131-480)
1972: (132-480)
1973: (133-480)
1974: (134-480A)
1975: (135-480A)
1976: (136-480A)

how to read serial numbers...
