Snapper HZ15420KVE


Snapper HZ15420KVE lawn tractor photo
1997 - 1998
Yard Cruiser Series
Zero-turn mower
Production
ManufacturerSnapper
TypeZero-turn mower
Snapper HZ15420KVE Engine
15HP Kohler 398cc 1-cyl gasoline
Fuel tank2.25 gal
8.5 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringpower
Brakeswet disc
CabOpen operator station.
Photos
No photos of the Snapper HZ15420KVE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Weight574 lbs
260 kg
Front tire11x4.00-4
Rear tire18x8.50-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps9
Battery CCA220
Battery volts12
References
HZ15420KVE reference literature
Legendary Quality published in 1997, by Snapper
Product Catalog published in 1998, by Snapper
