Lawn Tractors > Snapper > 331416KVE SR1433

Snapper 331416KVE SR1433

Snapper 331416KVE SR1433 lawn tractor photo
1997 - 1998
Riding lawn mower






Production:

Manufacturer:Snapper


Snapper 331416KVE Engine:

   14HP Kohler 398cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:1.75 gal [6.6 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:manual


Dimensions & Tires:

Weight:379 lbs [171 kg]
Front tire:11x4.00-4
Rear tire:16x7.50-8
full dimensions and tires ...


Snapper 331416KVE attachments:

 33" mid-mount mower deck
 blade
all 331416KVE attachments ...


331416KVE Serial Numbers:


how to read serial numbers...



Mechanical:

Transmission:5-speed friction disc
Chassis:4x2 2WD
Steering:manual
Brakes:drum
Cab:Open operator station.


Electrical:

Ground:negative
Charging amps:3


Battery:

Number:1
Cold-cranking amps:140
Volts:12
