New Holland CM272


New Holland CM272 lawn tractor photo
1990 - 2000
CM Series
Front-mount mower
Series:CM224CM272CM274
Production
ManufacturerNew Holland
TypeFront-mount mower
New Holland CM272 Engine
27HP Shibaura 1268cc 3-cyl diesel
Fuel tank10.6 gal
40.1 L
Engine details ...
Mechanical
Chassis4x2 2WD
Differential lockmechanical
Steeringpower
Brakesdrum
CabTwo-post foldable ROPS. Optional four-post ROPS canopy and soft cab.
Dimensions & Tires
Wheelbase49.2 inches
124 cm
Weight1492 lbs
676 kg
Front tire23x10.50-12
Rear tire18x7.00-8
Full dimensions and tires ...
New Holland CM272 attachments
60" front-mount mower deck
72" front-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps35
Battery volts12
