Craftsman 536.9633
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | Murray |
| Lawn tractor | |
| Original price was $444 in 1974 | |
| Craftsman 536.9633 Engine | |
| 8HP Tecumseh 305cc 1-cyl gasoline | |
| Fuel tank | 1 gal 3.8 L |
 Engine details ... | |
| Craftsman 536.9633 Transmission | |
| 3-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Craftsman 536.9633 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Weight | 380 lbs 172 kg |
| Front tire | 16x6.00 |
| Rear tire | 18x9.50 |
 Full dimensions and tires ... | |
| Craftsman 536.9633 attachments | |
| 36" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| References | |
 | |
| 1974 Suburban Farm and Ranch Catalog published by Sears | |
| Spring and Summer Catalog published in 1975, by Sears |
