Deutz-Allis 1036 Sprint


Deutz-Allis 1036 Sprint lawn tractor photo
1987 - 1992
Riding lawn mower
1036
Series:1036 Sprint
Production
Manufacturer:Deutz-Allis
Type:Riding lawn mower
Deutz-Allis 1036 Engine
10HP Briggs & Stratton 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
Transmission:5-speed gear
Transmission details ...
Photos
No photos of the Deutz-Allis 1036 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:1.25 gal
4.7 L
Dimensions & Tires
Weight:393 lbs
178 kg
Front tire:4.10x3.50-4
Rear tire:16x6.50-8
Full dimensions and tires ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
