MTD 990


MTD 990 lawn tractor photo
1971 - 1984
Model year
900 Series
Garden tractor
Production
ManufacturerMTD
Garden tractor
Built in Strongsville, Ohio, USA
Variants
960gear
990hydrostatic
MTD 990 Engine
16HP Briggs & Stratton 531cc 1-cyl gasoline
Fuel tank4.5 gal
17.0 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical disc brakes
Open operator station.
Tractor hitch
Rear Type0 OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Wheelbase49.5 inches
125 cm
Weight875 lbs
396 kg
Front tire16x6.50-8
Rear tire27x9.50-15
Full dimensions and tires ...
MTD 990 attachments
42" mid-mount mower deck
50" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
990 references literature
Lawn & Garden Tractor Accessories published in 1980, by MTD
Lawn and Garden Power Equipment published in 1977, by Agway
1977 Tractors published by MTD
Lawn & Garden Tractors published in 1981, by MTD
990 manuals literature
MTD Parts Microfiche (770-0273) published in 1980
MTD Parts Microfiche (770-1155) published in 1981
MTD Parts Microfiche (770-2200) published in 1982
Parts and Service Information Manual (770-1737) published in 1982
