Lawn Tractors > Kubota > ZD1211

Kubota ZD1211

Kubota ZD1211 lawn tractor photo
2016 -    ZD1200 Series
Zero-turn mower
Series next:Kubota ZD1211L






Production:

Manufacturer:Kubota


Kubota ZD1211 Engine:

   24.8HP Kubota 1123cc 3-cyl diesel
full engine details ...


Capacity:

Fuel:12.9 gal [48.8 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:hydraulic wet disc


Dimensions & Tires:

Wheelbase:56.7 inches [144 cm]
Weight:1687 lbs [765 kg]
Front tire:15x6.0-6
Rear tire:26x12.0-16
full dimensions and tires ...


Kubota ZD1211 attachments:

 60" mid-mount mower deck
all ZD1211 attachments ...


ZD1211 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS.


Electrical:

Ground:negative
Charging amps:14
Charging volts:14


Battery:

Number:1
Cold-cranking amps:430
Volts:12


Page information:

Last update:November 3, 2016
Copyright:Copyright 2016 TractorData LLC
Contact:Peter@TractorData.com
