Simplicity Sovereign 3416H 990871

Simplicity Sovereign 3416H 990871 lawn tractor photo
1973 - 1974   Sovereign Series
Garden tractor
Previous model:Simplicity 3415H






Production:

Manufacturer:Simplicity


Variants:

3416S:shuttle
3416H:hydrostatic


Simplicity 3416H Engine:

   16HP Briggs & Stratton 531cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:3 gal [11.4 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:mechanial idler pulley


Dimensions & Tires:

Wheelbase:48 inches [121 cm]
Front tire:16x6.50-8
Rear tire:23x10.50-12
full dimensions and tires ...


Simplicity 3416H attachments:

 42" mid-mount mower deck
 48" mid-mount mower deck
all 3416H attachments ...


3416H Serial Numbers:

Location:Serial number tag on the left side of the platform, above the foot rest.
photo of 3416H serial number


how to read serial numbers...



Mechanical:

Transmission:hydrostatic
Steering:manual
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
