White FR-16 Turf Boss


White FR-16 Turf Boss lawn tractor photo
1993 - 1995
FR Series
Front-mount mower
Production
Manufacturer:White (a part of MTD)
Type:Front-mount mower
White FR-16 Engine
16HP Briggs & Stratton 2-cyl gasoline
Engine details ...
Mechanical
Chassis:3x2 2WD
Steering:power
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the White FR-16 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:5 gal
18.9 L
Power Take-off (PTO)
Front PTO:independent
Clutch:electro-magnetic
Dimensions & Tires
Wheelbase:41 inches
104 cm
Weight:660 lbs
299 kg
Front tire:16x7.50-8
Rear tire:15x6
Full dimensions and tires ...
White FR-16 attachments
42" front-mount mower deck
52" front-mount mower deck
snowblower
blade
Attachment details ...
FR-16 Serial Numbers
Location:Model codes shown.
1993: 133-006-190
1994: 134-006-190
1995: 135-006-190

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Battery
Number:1
Cold-cranking amps:160
Volts:12
