Lawn Tractors > Steiner > 440

Steiner 440

Steiner 440 lawn tractor photo
2012 - 2015
Garden tractor






Production:

Manufacturer:Steiner


Variants:

75-72011:gas Kubota
75-72012:34hp gas Kohler
75-72013:40hp gas Kohler


Steiner 440 Engines:

   24.8HP Kubota 898cc 3-cyl diesel
   32.4HP Kubota 962cc 3-cyl gasoline
   34HP Kohler 999cc 2-cyl gasline
   40HP Kohler 999cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:8 gal [30.3 L]
Hydraulic system:5 gal [18.9 L]


3-Point Hitch:

Rear Type:I*Optional


Power Take-off (PTO):

Front PTO:independent
Clutch:electric


Dimensions & Tires:

Wheelbase:43.5 inches [110 cm]
Weight:1489 to 1517 pounds
Front tire:22x11-10
Rear tire:22x11-10
full dimensions and tires ...


Steiner 440 attachments:

 48" front-mount mower deck
 60" front-mount mower deck
 snowblower
 blade
all 440 attachments ...


440 Serial Numbers:


how to read serial numbers...



Mechanical:

Transmission:hydrostatic
Chassis:4x4 articulated 4WD
Steering:articulated power
Brakes:dry disc
Cab:Two-post folding ROPS.


Hydraulics:

Capacity:5 gal [18.9 L]
Pressure:1500 psi [103.4 bar]
Pump flow:6 gpm [22.7 lpm]


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
