Steiner 235


Steiner 235 lawn tractor photo
2010 - 2020
Garden tractor
Production
ManufacturerSteiner
TypeGarden tractor
Variants
75-7028225HP liquid-cooled diesel Kubota
75-7028335HP air-cooled gas Vanguard
Steiner 235 Engines
24.8HP Kubota 1122cc 3-cyl diesel
35HP Briggs & Stratton 991cc gasoline
Fuel tank6 gal
22.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringpower
Brakesdrum
CabOpen operator station. ROPS optional.
Photos
No photos of the Steiner 235 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase50 inches
127 cm
Weight1420 lbs
644 kg
Front tire24x11-2
Rear tire18x8.50-8
Full dimensions and tires ...
Steiner 235 attachments
60" front-mount mower deck
72" front-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
235D Charging amps40
235G Charging amps20
235D Battery CCA620
235G Battery CCA525
Battery volts12
References
235 reference literature
2017 Steiner Product Catalog engineered for unmatched versatility
