Homelite T-16H


Homelite T-16H lawn tractor photo
1973 - 1976
Model year
Garden tractor
Simplicity built
Production
DistributorHomelite (a part of Textron)
ManufacturerSimplicity
Garden tractor
Original price was $1,695 in 1975
Variants
T-16Sshuttle
T-16Hhydrostatic
Homelite T-16H Engine
16HP Briggs & Stratton 531cc 1-cyl gasoline
Fuel tank2.5 gal
9.5 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Drum brakes
Open operator station.
Photos
No photos of the Homelite T-16H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase48.1 inches
122 cm
Weight900 lbs
408 kg
Front tire16x6.50-8
Rear tire23x10.50-12
Full dimensions and tires ...
Homelite T-16H attachments
42" mid-mount mower deck
48" mid-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps14
Battery volts12
References
T-16H references literature
Hydrostatic Drive Owners Manual published in 1973
