Ariens Fairway 6


Ariens Fairway 6 lawn tractor photo
1969 - 1971
Model year
Fairway Series
Riding lawn mower
Series:Fairway 5Fairway 6
Production
Manufacturer:Ariens
Type:Riding lawn mower
Factory:Brillion, Wisconsin, USA
Variants
12983:recoil start
12982:electric start
Mechanical
Chassis:4x2 2WD
Steering:manual
Brakes:mechanical band
Cab:Open operator station.
Transmission:4-speed friction disk
Transmission details ...
Photos
No photos of the Ariens Fairway 6 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:0.5 gal
1.9 L
Power Take-off (PTO)
Mid PTO:independent
Clutch:mechanical idler
Dimensions & Tires
Wheelbase:46.5 inches
118 cm
Weight:298 lbs
135 kg
Front tire:4.10x3.50-4
Rear tire:13x5.00-6
Full dimensions and tires ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
