Lawn Tractors > Bolens > FS 943

Bolens FS 943

Bolens FS 943 lawn tractor photo
1985 - 1987   Frame Steer Series
Articulated front-mount mower
Previous model:Bolens 942
Next model:Bolens 944






Production:

Manufacturer:Bolens


Bolens 943 Engine:

   11HP Briggs & Stratton 399cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:1.8 gal [6.8 L]


Dimensions & Tires:

Weight:443 lbs [200 kg]
Front tire:16x6.50-8
Rear tire:16x6.50-8
full dimensions and tires ...


Bolens 943 attachments:

 42" front-mount mower deck
all 943 attachments ...


943 Serial Numbers:


how to read serial numbers...



Mechanical:

Transmission:5-speed gear
Chassis:4x2 2WD
Steering:manual articulated
Brakes:disc
Cab:Open operator station.


Electrical:

Charging amps:5


Battery:

Number:1
Cold-cranking amps:160
Volts:12
