Lawn Tractors > Craftsman > 917.25763 LT4000

Craftsman 917.25763 LT4000

Craftsman 917.25763 LT4000 lawn tractor photo
1994 - 1994
Lawn tractor






Production:

Distributor:Sears
Manufacturer:AYP


Craftsman 917.25763 Engine:

   13HP Briggs & Stratton 465cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:1.25 gal [4.7 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:manual


Dimensions & Tires:

Front tire:15x6.0-6
Rear tire:18x8.5-8
full dimensions and tires ...


Craftsman 917.25763 attachments:

 42" mid-mount mower deck
all 917.25763 attachments ...


917.25763 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:6-speed gear
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.


Electrical:

Ground:negative
Charging amps:3 (battery)
 5 (headlights)


Battery:

Number:1
Volts:12


Page information:

Last update:September 18, 2015
