Lawn Tractors > Simplicity > Broadmoor 18H

Simplicity Broadmoor 18H



Simplicity Broadmoor 18H lawn tractor photo
1997 - 2004
Model year
Broadmoor Series
Lawn tractor
Production
ManufacturerSimplicity
Lawn tractor
Simplicity Broadmoor 18H Engine
18HP Vanguard 570cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Simplicity Broadmoor 18H Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Photos
No photos of the Simplicity Broadmoor 18H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase52 inches
132 cm
Weight701 lbs
317 kg
Front tire15x6.0-6
Rear tire20x10-10
Full dimensions and tires ...
Simplicity Broadmoor 18H attachments
50" mid-mount mower deck
Attachment details ...
References
Broadmoor 18H references literature
The Way To A Beautiful Lawn published in 2004, by Simplicity
