Craftsman 502.25411


No photo available
1991 - 1993
Riding lawn mower
Murray built
Series map:
502.25411
502.25418
5.0hp
8.0hp
Production
DistributorCraftsman (a part of Sears)
ManufacturerMurray
Riding lawn mower
Original price was $1,199 in 1993
Craftsman 502.25411 Engine
5HP Tecumseh 199cc 1-cyl gasoline
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Open operator station.
Photos
No photos of the Craftsman 502.25411 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Weight486 lbs
220 kg
Front tire11x4
Rear tire16x6.50
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
502.25411 references literature
1993 Spring/Summer Annual published by Sears
