Ariens S-8H 929002


Ariens S-8H 929002 lawn tractor photo
1974 - 1978
Lawn tractor
Production
Manufacturer:Ariens
Type:Lawn tractor
Factory:Brillion, Wisconsin, USA
Variants
S-8G:gear
S-8H:hydrostatic
Ariens S-8H Engine
8HP Briggs & Stratton 318cc 1-cyl gasoline
Engine details ...
Mechanical
Steering:manual
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Ariens S-8H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:1.375 gal
5.2 L
Power Take-off (PTO)
Front PTO:independent
Clutch:mechanical pulley
Dimensions & Tires
Wheelbase:43 inches
109 cm
Weight:450 lbs
204 kg
Front tire:15x6.00-6
Rear tire:20x8.00-10
Full dimensions and tires ...
Ariens S-8H attachments
36" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
