Lawn Tractors > Ariens > HT18 934002

Ariens HT18 934002

No photo available
1986 - 1995
Model years
Garden tractor






Production:

Manufacturer:Ariens
Factory:Brillion, Wisconsin, USA


Ariens HT18 Engine:

   18HP Briggs & Stratton 694cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:4.5 gal [17.0 L]


Rear Hitch:

Type:sleeve hitch*Optional


Power Take-off (PTO):

Rear PTO:independent*Optional
Clutch:mechanical pulley
Mid PTO:independent
Clutch:mechanical pulley


Dimensions & Tires:

Wheelbase:48 inches [121 cm]
Front tire:15x6.00-6
full dimensions and tires ...


Ariens HT18 attachments:

 42" mid-mount mower deck
 48" mid-mount mower deck
 blade
all HT18 attachments ...


HT18 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:4-speed gear
Steering:manual
Brakes:disc
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
