Kubota ZG23
|
|
| Production | |
| Manufacturer | Kubota |
| Zero-turn mower | |
| Kubota ZG23 Engine | |
| 23HP Kubota 673cc 2-cyl gasoline | |
| Fuel tank | 6.1 gal 23.1 L |
 Engine details ... | |
| Kubota ZG23 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Steering | differential power |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
 | |
 Kubota ZG23 photos... | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Mid PTO Type | Kubota 10-tooth |
| Dimensions & Tires | |
| Wheelbase | 46.7 inches 118 cm |
| Weight | 1102 lbs 499 kg |
| Front tire | 13x5.0-6 |
| Rear tire | 23x10.5-12 |
 Full dimensions and tires ... | |
| Kubota ZG23 attachments | |
| 54" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery CCA | 285 |
| Battery volts | 12 |
| Battery Group | U1L-9 |
| References | |
 | |
| Zero-Turn Mower ZG published in 2003, by Kubota |
