Lawn Tractors > Kubota > ZG20

Kubota ZG20

No photo available
2003 - 2007   ZG Series
Zero-turn mower






Production:

Manufacturer:Kubota


Kubota ZG20 Engine:

   20HP 624cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:6.1 gal [23.1 L]


Power Take-off (PTO):

Mid PTO:independent


Dimensions & Tires:

Wheelbase:46.7 inches [118 cm]
Weight:1058 lbs [479 kg]
Front tire:13x5.0-6
Rear tire:23x10.5-12
full dimensions and tires ...


Kubota ZG20 attachments:

 48" mid-mount mower deck
all ZG20 attachments ...


ZG20 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:differential power
Brakes:wet disc
Cab:Two-post foldable ROPS.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
