Kubota ZP330

Kubota ZP330 lawn tractor photo
2012 -    Z300 Series
Zero-turn mower






Production:

Manufacturer:Kubota
Original price (USD)
   $15,861 (2015 60-inch )
   $16,422 (2015 72-inch )


Kubota ZP330 Engine:

   31HP Kubota 962cc 3-cyl LP-gas
full engine details ...


Capacity:



Power Take-off (PTO):

Mid PTO:independent
Clutch:hydraulic wet disc


Dimensions & Tires:

Wheelbase:55.5 inches [140 cm]
Weight:1876 to 1940 pounds
Front tire:15x6.0-6
Rear tire:26x12.0-12
full dimensions and tires ...


Kubota ZP330 attachments:

 60" mid-mount mower deck
 72" mid-mount mower deck
all ZP330 attachments ...


ZP330 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:differential power
Brakes:wet discs
Cab:Two-post foldable ROPS.


Electrical:

Ground:negative
Charging amps:14
Charging volts:14


Battery:

Number:1
Cold-cranking amps:475
Volts:12
