Kubota ZD326


Kubota ZD326 lawn tractor photo
2007 - 2017
Z300 Series
Zero-turn mower
Production
ManufacturerKubota
TypeZero-turn mower
Original price$14,586 (2015 )
Kubota ZD326 Engine
26HP Kubota 1001cc 3-cyl diesel
Fuel tank12.9 gal
48.8 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringdifferential power
Brakeswet discs
CabTwo-post foldable ROPS.
Photos
No photos of the Kubota ZD326 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchhydraulic wet disc
Dimensions & Tires
Wheelbase55.5 inches
140 cm
Weight1700 lbs
771 kg
Front tire15x6.0-6
Rear tire26x12.0-12
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps14
Charging volts14
Battery CCA475
Battery volts12
References
ZD326 reference literature
Z200/Z300 Series published in 2016, by Kubota
